Installation
Light source
29 (1.1)
ø 4.1
(.16 dia.)
M4 x 6
45 (1.77)
Fig. 4 dimensional drawing ODC 1201, ranges 20/30 mm, dimensions in mm, not to scale
Aperture dimensions
(A x B) in mm
optoCONTROL 1200/1201
110 (4.33)
68 (2.68)
Laser light
max. 5000 (197)
60 (2.36)
Model
ODC1201-20
ODC1201-30
Receiver
87 (3.43)
45 (1.77)
29 (1.14)
ø 4.1
(.16 dia.)
M4 x 6
37 45
(1.46)
(1.77)
Light source Receiver
20 x 2 (.79 x .08) 20 x 0.3 (.79 x .01)
30 x 2 (1.18 x .08) 30 x 0.3 (1.18 x .01)
17 (.67)
34
(1.34)
