Functional Principle, Technical Data
3.3
Technical Data
Model
Measuring range
Limit frequency
Smallest detectable
object
Distance light source - receiver (Free space)
Linearity
3)
Resolution (dynamic)
Light source
Permissible ambient light
Analog output
Switching outputs
Shock
Vibration
Operating temperature
Storage temperature
Operating voltage
Mounting holes
optoCONTROL 1200/1201
ODC 1200 (axial model)
mm
2
5
1 % FSO
0.02
0.05
mm
1)
% FSO
±2
µm
10
25
Semiconductor laser, 670 nm (red), Laser class 1; P ≤ 0.39 mW
Switching output PNP dark switching and NPN bright switching (max. switching
straight up
horizontal
ODC 1200/90 (90 ° model)
10
16
2
5
2)
100 kHz (-3 db)
0.1
0.16
0.02
0.05
min. 20 mm up to max. 5 m
±3.5
±2
50
80
10
25
≤ 5000 lx
0 ... 10 VDC (Gain adjustable)
frequency 60 kHz)
15 g / 6 ms
15 g / 10 Hz / ...1 kHz
0 ... 50 °C (+32 to +122 °F)
-20 ... 70 °C (-4 to +158 °F)
12 - 32 VDC, reverse polarity protection
M4 x 5 mm
M5 x 8 mm
ODC 1201
10
16
20
0.1
0.16
0.2
±3.5
50
80
100
4)
ø 4.1 mm
M4 x 6 mm
30
0.3
150
