Taurus TF-WS7-ATT Bedienungsanleitung Seite 67

Nr. Bezeichnung (ENG)
33 seat cushion tube
34 leg curl elbow tube
35 big washer
36 hexagon bolt
37 pull pin
38 shaft
39 shaft
40 front push holder
41 guard plate
42 front push arm
43 hexagon bolt
44 hexagon socket button head bolt
45 right butterfly arm
46 left butterfly arm
47 pulley support frame
48 reinforcing plate
49 footplate
50 hexagon bolt
51 hexagon bolt
52 hexagon bolt
53 hexagon socket button head bolt
54 "-" shape pulley frame
55 pulley
56 connecting sleeve
57 pulley spacer
58 lat pull cable
59 cable hook
60 9 link chain & snap hook
61 double pulley plate
62 middle cable
63 hexagon bolt
64 butterfly arm cable
65 hexagon bolt
Maße
Φ25*10*2.0
M8*16
Φ12
Φ17*134
Φ17*100
M10*70
M10*16
M10*130
M10*115
M10*45
M10*45
Φ95*26
Φ14*100
Φ22*Φ10.5*45.5
L:4540mm
L:1500mm
M8*45
L:5375mm
M10*75
Anz.
1
1
6
9
1
1
1
1
1
1
1
2
1
1
1
1
1
6
2
19
1
2
27
1
4
1
1
5
1
1
4
1
2
67
