Oscillator parameters
Parameter Description
Waveform Oscillator waveform
Transpose -12 to +12 semitones in one-semitone steps
Octave -5 to +5 in one-octave steps
Mode Oscillator mode.
Group Modulation mode.
See “"Oscillator modulation modes”" on page 24.
ON/OFF toggle Enable/disable the oscillator.
Tip: You can hold down the CTRL (Windows)/Command (OSX) key and click an
oscillator number to enable/disable the oscillator, or hold down the SHIFT key to solo the
oscillator.
Fine -100 to +100 cents fine-tune adjustment
Phase (Spread in 0 to 360 degrees start phase adjustment.
Multi mode) This slider becomes “"Multi Detune”" when Multi mode is used.
Bus Mixing bus assignment, from full Bus1 to full Bus2
Level Output level of the oscillator
Table 7. Oscillator parameters
Oscillator modes
Mode Description
NSYNC Normal polarity, key sync.
This is the standard mode. The phase of the oscillator will start on the point set by the Phase
control on every Note-On event.
ISYNC Inverted polarity, key sync.
Same as NSYNC, but with the output polarity of the oscillator inverted.
NFREE Normal polarity, free running.
The oscillator phase doesn’'t restart on Note-On events. Preferred mode for monophonic
sounds.
IFREE Inverted polarity, free running.
Same as NFREE, but with the output polarity of the oscillator inverted.
Table 8. Oscillator modes
