There are two output buses for mixing oscillators, each of which have a filter, and buses can be
panned. Later, at the filter stage, the filters' output is panned in the stereo field. This design lets you
create mono or stereo programs and position individual oscillators precisely in the stereo field. So
you have two ways to control the pan position of an oscillator: (1) determine how much of its signal
goes to each bus, and (2) determine the pan position of the output of each filter.
Parallel mode
BUS 1
OSC1
OSC2
FILTER 1
PAN 1
LEFT
You can adjust the pitch, phase, level and startup behavior of every oscillator individually by using
the appropriate controls.
The Synthesizer
BUS 2
FILTER 2
PAN 2
RIGHT LEFT
C
Dual mode
BUS 1 BUS 2
OSC1
OSC2
FILTER 1 FILTER 1
FILTER 2 FILTER 2
PAN 2
PAN 1
RIGHT
