Options menu

Figure 5. Options menu button
Command
Velocity Curve
Show MIDI Configuration
File
Real-time Quality
Off-line Quality
Precision
Load Tuning File
Lock Tuning to <current
tuning file> for All Programs
Reset to Standard Tuning
Bypass Effects
Arpeggiator
Hide preview ribbon
Table 2. Options menu commands
12
Interacting with Z3TA+: Graphical User Interface (GUI)
Description
Sets the velocity curve response.
Shows the MIDI configuration file, showing what parameters are ready to
receive MIDI CCs.
Sets the real-time oversampling mode.
Sets the offline oversampling mode.
Sets the output quality to Low, Medium, High, or Highest.
Low: Bandwidth is limited to one-fourth of the selected sample rate (for
example, 11KHz @44100). Little high-frequency content is generated.
Heavily filtered programs (for example, the Boom Bass factory preset) don’'t
need the full oscillator bandwidth, as it would be removed in the next synthesis
stage (the filter). In these cases, using Low mode allows for significant CPU
savings.
Medium: Standard mode for most programs. Standard-order interpolation and
control rate settings are used, so full bandwidth is expected.
High: Higher-order interpolation is activated, and control rate is increased
(perceivable when modulating individual oscillator levels or individual EQ bands
with high-transition sources, such as an LFO with square wave).
Highest: The Highest' quality mode improves audio precision with higher-order
windowed-sinc resampling of waveforms and noise-shaped dithering.
The High or Highest mode is the preferred mode for final renderings.
Windows: Opens the Load Tuning File dialog box, which lets you load any
available Scala tuning file.
OSX: Opens the Load Tuning File Finder window, which lets you load any
available Scala tuning file.
For details, see “"Microtuning, alternative tunings”" on page 66.
Applies the current tuning file to all programs.
Resets Z3TA+ to use the default equal temperament tuning.
Bypasses all effects.
•• Disable
•• Auto disable when dragging pattern to host
•• Auto Fit Patterns to 1 Measure When Loaded
Hide the preview ribbon and reduce the size of the UI.
