PRINTOUT OF THE WELDING DATA

14. Printout of the welding data
PRINTOUT
JUSTIFYING
PRINTOUT
PRINTER
PRINTOUT
PUSH VALID
TO START
PRINTING
DELETE REPORTS?
31 31 31
HISTORICAL
PRINTOUT
PC
PRINTOUT
PUSH VALID
TO START
PRINTING
YES
Select the type of printout required using "+" and "-" and
confirm with "VALID". Justification = printout of the last
welding operation only Log = printout of all the welding
operations which are in the memory. In the case of the
justification printout go directly to the third point.
Select the type of printer used with "+" and "-"
and confirm with
PC = Connect the welding machine to a PC by using an RS 232
serial cable (see table 2)
Printer = Connect the printer to the serial socket RS 232.
By pressing "RESET" it is possible to stop the printout in
progress.
At the end of the printout (or if it was cancelled) a message
asks whether to delete the reports. Choose with "+" or "-"
and press "VALID" to confirm the selection (this operation is
only possible for the log printout).
ENGLISH
"VALID". Confirm with "VALID".
