INSTRUCTIONS FOR USE
Move from one to the other using the + and – keys.
Use the MENU button to confirm the 'Daily program'option and access the selection of the number of programs (ignition/shutdown) to be set per day.
Use the 'Program/daily' option to set the identical program/s for every day of the week.
The following will be displayed if the + key is pressed:
- No Prog.
- Prog. No. 1 (one ignition and one shutdown per day), Prog. No. 2 (same as before), Prog. No. 3 (same as before)
Use the button to show them in reverse order. If the 1st program is selected, the ignition time is shown.
The display shows: 1 Ignition Hour 10.30; use the +/– keys to change the hour and press MENU to confirm.
The display shows: 1 Ignition Minutes 10.30; use the +/– keys to change the minutes and press MENU to confirm.
In the same way, adjust the shutdown times.
The program is confirmed by pressing the MENU button when "Saved" appears on the display.
When confirming 'Program/week', you will need to choose the day to which the program is to apply:
1 Mon; 2 Tues; 3 Wed; 4 Thurs; 5 Fri; 6 Sat; 7 Sun
Once you have chosen the day by scrolling through them with the + and – keys, confirm by pressing MENU and proceed with the
settings of the programs in the same way as for the 'Program/daily', selecting whether or not to enable a program for each day of the
week and choosing the number and times of interventions.
Should you make a mistake whilst setting the programs you can exit without saving by pressing the 0/1 key and 'Saved' will appear
on the display.
Should the hopper run out of pellets, the stove will block and 'Stop/Flame' will appear.
Pellet reserve warning
The thermal stoves are equipped with an electronic pellet detection system.
The pellet detection system is integrated into the electronic control board, allowing the stove to monitor how many kilos of pellets are
left.
This verification is implemented at any point whilst the stove is in operation mode.
For correct system operation, it is important that the following procedure is adhered with during the first ignition (that must be imple-
mented by the DEALER). Before starting to use the pellet detection system, you must load and consume a full sack of pellets.
This allows for a brief running-in of the loading system.
Subsequently load 15 kg of pellets.
Then press the 'reserve' button once, thereby storing the data into the memory that 15 kg have been loaded.
From now on the display will show the remaining pellets as they decrease in kg (15...14...13). Each time pellets are reloaded you must
enter the quantity. E.g. when loading 15 kg, simply press the 'pellet load' button to enter this into the memory.
For other quantities, or in the event of an error, you can specify the quantity using the pellet reserve menu as follows:
Press the MENU button for 2 seconds to view the SETTINGS.
Press + or – consecutively to view T. Max exit.
Confirm by pressing MENU and the remaining quantity of pellets will be displayed + that being loaded (default is 15 and can be chan-
ged using the +/- keys).
Should the hopper run out of pellets, the stove will block and 'Stop/Flame' will appear.
