h) Setting Signal Command

The signal command determines the reactions of the receiver when a switching signal is
received. Different reactions are possible (see table below).
Number pair
to be entered
11
12
13
14
21
22
23
24
31
32
33
34
41
42
43
44
Please note:
As a switching signal is sent by each of the two channels, the most practicable application is
the predominant use of switching commands that only activate the FS20 devices for a specific
period of time.
The programming of both channels to an address creates further switching possibilities; thus,
instead of the switching command "On for the activation period" you can program "On" to one
channel and the command "Off" to another channel – allowing you to select the on and off
switching temperatures completely independently of one another, for example switching
heating on below +10°C and switching off at +20°C.
Signal command
On (at old dim setting)
Off
On (dim setting 12.5%)
On (dim setting 25.0%)
On (dim setting 37.5%)
On (dim setting 50.0%)
On (dim setting 62.5%)
On (dim setting 75.0%)
On (dim setting 87.5%)
On (dim setting 100%)
Off for the activation period
On (at old dim setting) for the activation period, then Off
On (at dim setting 100%) for the activation period, then Off
On (at old dim setting) for the activation period, then back to
old status (command is not supported by all receivers)
On (at dim setting 100%) for the activation period, then back to
old status (command is not supported by all receivers)
On (at old dim setting)
