Individual address
Function group address
Local master address
Global master address
44 = This value must be set to "44".
44 = This value must not be set to "44".
The allowed values are:
11, 12, 13, 14, 21, 22, 23, 24, 31, 32, 33, 34, 41, 42, 43
Every receiver can be assigned an address from each of the four different address types
(individual address, function group address, local master address, and global master address).
This means each receiver can react to up to four different addresses, but only one address per
address type.

If a receiver is intended to react to several transmitters, the transmitter can be
programmed to the same address or, in the case of differently set transmitter
address types, the receiver can be progressively programmed to the different
addresses.
The individual address type is intended for the following function:
• Individual addresses
Each receiver should be set to a single address in order for it to be able to be separately
controlled.
• Function group address
Several receivers are defined as a functional unit by the allocation of a function group
address. If for example, all the lamps in a house are assigned to a function group the entire
house can be lit or darkened by the touch of a single button.
42
Address groups
44
44
44
44
Sub-address
44
44
44
44
