4.3.2.2. Kommunikation über die integrierte PN-Schnittstelle der CPU
FB100
Registration_Code
Line_ID
L1_Active_Connect_C1
L1_Acceppt_All_IP_Adr_C1
L1_IP_Address_HH_C1
L1_IP_Address_HL_C1
L1_IP_Address_LH_C1
L1_IP_Address_LL_C1
L1_TCP_Port_Number_C1
L1_Active_Connect_C2
... _C2
L1_TCP_Port_Number_C2
L1_C2_over_CPU_Rack_1
*1)
L2_T104_T0
L2_T104_T1
L2_T104_T2
L2_T104_T3
L2_T104_k
L2_T014_w
L2_Error_DelayTime
L2_Ack_Buf_Dim
L7_Block_Len
Buffer_Handling
Do_Restart
First_internal_DB_No
No_of_Send_Buffers
Send_Buffer_Dim
SIPLUS RIC IEC on S7 V1.5
Funktionsbeschreibung
Typ
Default
IN
DWORD
DW#16#0
IN
INT
1
IN
BOOL
FALSE
IN
BOOL
TRUE
IN
INT
0
IN
INT
0
IN
INT
0
IN
INT
0
IN
INT
2404
IN
BOOL
FALSE
IN
IN
INT
2405
IN
Bool
FALSE
IN
Time
T#30S
IN
Time
T#15S
IN
Time
T#10S
IN
Time
T#20S
IN
INT
12
IN
INT
8
IN
TIME
T#10S
IN
INT
0
IN
INT
120
IN
BYTE
B#16#0
IN
BOOL
FALSE
IN
INT
50
IN
INT
2
IN
DINT
L#4096
Seite 57 von 235
Baustein-Kommentar / Kurzbeschreibung
!!! IMPORTANT !!! See product information
for differentiation of more than one line;1-x (see ma-
nual); Default: 1;
0 (default): we are passive (listen); 1: we (active) try to
establish the con...
0:Only one defined IP-Addr. ... 1 (Default): Each IP-
Address will be accepted
xxx-Part of IP-Address xxx.0.0.0 ; only needed if 'ac-
cept all' = false
xxx-Part of IP-Address 0.xxx.0.0 ; only needed if 'ac-
cept all' = false
xxx-Part of IP-Address 0.0.xxx.0 ; only needed if 'ac-
cept all' = false
xxx-Part of IP-Address 0.0.0.xxx ; only needed if 'ac-
cept all' = false
Connections will be accepted or established with this
port (Def:2404)
0 (default): we are passive (listen); 1: we (active)try to
establish the con...
Parameter für 2te TCP-Verbindung (wie _C1)
Connections will be accepted or established with this
port (Def:2405)
only for H-System; If set C2 will communicate via CPU
in Rack 1
1-255 sec/Def:30/Time-out of connection establish-
ment
1-255 sec/Def:15/Time-out of send or test APDUs
1-255 sec/Def:10/Time-out for acknowledges in case
of no data messages t2<t1
1s-48h/Def:20s/Time-out for sending test frames in
case of a long idle state
>1/Def:12/Maximum
difference
number to send state variable
>1/Def:8/Latest acknowledge after receiving w I-format
APDUs
Def: 10 sec: after this time L2_Error_Link will be set, if
no con. is active
0(def): without; <>0 (we suggest 1600): dimension
[byte] of ack-buffer;
max. length of T101/104-ASDU (1..255, see manual);
Default 120
0(def): compl, 1:compl. if ov 2:oldest Info will deleted;
3:no act.
a rising edge restarts the IEC-Application
First DB-Number for DBs created by the Runtime
Software; Default: 50.
Default 2;Number of Send buffers (with send priority 1
to this para)
Dimension [size in byte] of the send buffers;
Default 4096
I IA CE
receive
sequence
©SIEMENS AG 2013
