AD629 RETSPL-HL Tabel
ANSI S3.6-2010
ISO 389-7 2005
Binaural
0°
Frequency RETSPL RETSPL
Hz dB
125 22
160 18
200 14.5
250 11.5
315 8.5
400 6
500 4.5
630 3
750 2.5
800 2
1000 2.5
1250 3.5
1500 2.5
1600 1.5
2000 -1.5
2500 -4
3000 -6
3150 -6
4000 -5.5
5000 -1.5
6000 4.5
6300 6
8000 12.5
WhiteNoise 0
ANSI S3.6-2010
0° 45°
RETSPL RETSPL
Speech 15 11
Speech Noise 15 11
Speech WN 17.5 13.5
ISO 389-7 2005
0° 45°
RETSPL RETSPL
Speech 0 -4
Speech Noise 0 -4
Speech WN 2.5 -1.5
Free Field
Binaural to
Monaural
45° 90° correction
RETSPL RETSPL
dB dB dB
21.5 21 2
17 16.5 2
13.5 13 2
10.5 9.5 2
7 6 2
3.5 2.5 2
1.5 0 2
-0.5 -2 2
-1 -2.5 2
-1.5 -3 2
-1.5 -3 2
-0.5 -2.5 2
-1 -2.5 2
-2 -3 2
-4.5 -3.5 2
-7.5 -6 2
-11 -8.5 2
-11 -8 2
-9.5 -5 2
-7.5 -5.5 2
-3 -5 2
-1.5 -4 2
7 4 2
-4 -5.5 2
ANSI
Binaural
90° 135° 180°
RETSPL RETSPL RETSPL
9.5 10 13
9.5 10 13
12 12.5 15.5
IEC Free Field
Binaural
90° 135° 180°
RETSPL RETSPL RETSPL
-5.5 -5 -2
-5.5 -5 -2
-3 -2.5 0.5
Free Field max HL is found by subtracting the selected RETSPL value
Tone
Max SPL
dB
102
98
104.5
106.5
103.5
106
104.5
103
102.5
107
102.5
103.5
102.5
106.5
103.5
101
104
104
104.5
108.5
104.5
106
92.5
Free Field
Free Field max HL is found by subtracting the selected RETSPL value
Binaural to
Monaural
correction
RETSPL
2
2
2
Free Field max HL is found by subtracting the selected RETSPL value
Binaural to
Monaural
correction
RETSPL
2
2
2
Free Field max SPL
Free Field Line
NB
Max SPL
dB
97
93
99.5
101.5
98.5
101
99.5
98
97.5
102
97.5
98.5
97.5
101.5
98.5
96
94
94
99.5
98.5
99.5
96
87.5
100
Free Field max SPL
Free Field Line
0° - 45° - 90°
Max SPL
100
100
97.5
Free Field max SPL
Free Field Line
0° - 45° - 90°
Max SPL
100
100
97.5
