Lenze 9400 Referenzhandbuch Seite 921

14 Parameter-Referenz
14.3 Attributtabelle
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Code Name
C00771 MCTRL_dnLoadPosAct
C00772 MCTRL_dnMotorSpeedAct
C00773 MCTRL_dnLoadSpeedAct
C00774 MCTRL_dnTorqueAct
C00775 MCTRL_dnOutputSpeedCtrl
C00776 MCTRL_dnInputJerkCtrl
C00777 MCTRL_dnInputTorqueCtrl
C00778 MCTRL_dnFluxAct
C00779 MCTRL_dnDCBusVoltage
C00780 MCTRL_dnImotAct
C00781 MCTRL_dwMaxMotorSpeed
C00782 MCTRL_dwMaxMotorTorque
C00783 MCTRL_dwMotorVoltageAct
C00784 MCTRL_dnMotorFreqAct
C00786 MCTRL_dnIxtLoad
C00787 MCTRL_dnFlyingSpeedAct
C00788 MCTRL_dwMaxEffMotorTorque
C00789 MCTRL_dwMaxDeviceCurrent
C00790 MCTRL_dnI2xtLoad
C00791 MCTRL_dnDeltaMotorPos_p
C00792 MCTRL_dnOutputPosCtrlMotor_s
C00800 MCTRL_dnPosSet
C00802 MCTRL_dnSpeedAdd
C00803 MCTRL_dnTorqueAdd
C00804 MCTRL_dnAccelerationAdd
C00805 MCTRL_dnSpeedLowLimit
C00806 MCTRL_dnTorqueLowLimit
C00807 MCTRL_dnTorqueHighLimit
C00808 MCTRL_dnPosCtrlOutLimit
C00809 MCTRL_dnTorqueCtrlAdapt
C00810 MCTRL_dnSpeedCtrlAdapt
C00811 MCTRL_dnPosCtrlAdapt
C00812 MCTRL_dnMotorPosRefValue
C00813 MCTRL_dnLoadPosRefValue
C00814 MCTRL_dnBoost
C00815 MCTRL_dnSpeedCtrlIntegrator
C00816 MCTRL_dnFieldWeak
C00817 MCTRL_dnSpeedSet_s
C00818 MCTRL_dnMvorAdapt
C00854 Identifikationsstatus
C00878 Status DCTRL-Steuereingang
C00909 Drehzahlbegrenzung
C00950 VFC: U/f-Kennlinienform
C00951 VFC: U/f-Eckfrequenz
C00952 VFC: Frequenz Kurvenstützpkt n
C00953 VFC: Spannung Kurvenstützpkt n
C00954 VFC: Aktiv. Kurvenstützpunkt n
C00955 VFC: Reduzierung Umax
C00957 VFC: Stromsollwert VVC
C00958 VFC: Verstärkung VVC
Grau hinterlegt = Anzeigeparameter (nur lesender Zugriff möglich)
Lenze · Servo-Inverter 9400 HighLine · Referenzhandbuch · DMS 10.0 DE · 11/2013 · TD05/06
Typ Index
dec hex
Linearer Wert 23804 5CFC
Linearer Wert 23803 5CFB
Linearer Wert 23802 5CFA
Linearer Wert 23801 5CF9
Linearer Wert 23800 5CF8
Linearer Wert 23799 5CF7
Linearer Wert 23798 5CF6
Linearer Wert 23797 5CF5
Linearer Wert 23796 5CF4
Linearer Wert 23795 5CF3
Linearer Wert 23794 5CF2
Linearer Wert 23793 5CF1
Linearer Wert 23792 5CF0
Linearer Wert 23791 5CEF
Linearer Wert 23789 5CED
Linearer Wert 23788 5CEC
Linearer Wert 23787 5CEB
Linearer Wert 23786 5CEA
Linearer Wert 23785 5CE9
Linearer Wert 23784 5CE8
Linearer Wert 23783 5CE7
Linearer Wert 23775 5CDF
Linearer Wert 23773 5CDD
Linearer Wert 23772 5CDC
Linearer Wert 23771 5CDB
Linearer Wert 23770 5CDA
Linearer Wert 23769 5CD9
Linearer Wert 23768 5CD8
Linearer Wert 23767 5CD7
Linearer Wert 23766 5CD6
Linearer Wert 23765 5CD5
Linearer Wert 23764 5CD4
Linearer Wert 23763 5CD3
Linearer Wert 23762 5CD2
Linearer Wert 23761 5CD1
Linearer Wert 23760 5CD0
Linearer Wert 23759 5CCF
Linearer Wert 23758 5CCE
Linearer Wert 23757 5CCD
Linearer Wert 23721 5CA9
Linearer Wert 23697 5C91
Linearer Wert 23666 5C72
Auswahlliste 23625 5C49
Linearer Wert 23624 5C48
Linearer Wert 23623 5C47
Linearer Wert 23622 5C46
Auswahlliste 23621 5C45
Linearer Wert 23620 5C44
Linearer Wert 23618 5C42
Linearer Wert 23617 5C41
Daten
DS DA DT Faktor
A 2 UNSIGNED_32
E 1 INTEGER_32
E 1 INTEGER_32
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32
E 1 INTEGER_32 100
E 1 UNSIGNED_32
E 1 UNSIGNED_32 1000
E 1 UNSIGNED_32
E 1 INTEGER_32 10
E 1 INTEGER_32 100
E 1 INTEGER_32
E 1 INTEGER_32 1000
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32
E 1 INTEGER_32
A 2 UNSIGNED_32
E 1 INTEGER_32
E 1 INTEGER_32 1000
E 1 INTEGER_32 1000
E 1 INTEGER_32
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32
E 1 INTEGER_32 100
E 1 INTEGER_32 100
E 1 INTEGER_32 100
A 2 UNSIGNED_32
A 2 UNSIGNED_32
E 1 INTEGER_32
E 1 INTEGER_32 1000
E 1 INTEGER_32 100
E 1 INTEGER_32
E 1 INTEGER_32 100
E 1 UNSIGNED_32
A 5 UNSIGNED_8
A 2 INTEGER_16 10
E 1 UNSIGNED_32
E 1 INTEGER_32
A 11 INTEGER_32
A 11 INTEGER_32 100
A 11 UNSIGNED_32
E 1 UNSIGNED_32
E 1 INTEGER_32 100
E 1 UNSIGNED_32 100
RSP
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 RSP
RSP
1 RSP
1
