3. Mounting the
Due to the specially packaging, the screw for VTA adjustment is completely screwed in for delivery.
Unity
To install the tonearm, it must be in the "0" position.
To do this, loose the locking screw on the tonearm foot (Pic. 9).
Pic. 9: Locking screw VTA adjustment
By turning the VTA screw counterclockwise, the tonearm lowers and the scale on the VTA unit
becomes negative.
Turning clockwise raises the tonearm; the scale of VTA unit becomes positive.
Now set this to "0" for the next assembly steps.
Pic. 10:
Scale of the VTA unit
