2.1 Mounting the tonearm base on the Clearaudio Reference Jubilee or Master Jubilee
turntable
I f you did not order your turntable together with the
the tonearm base, as usually a tonearm base for 9 inch tonearms is pre-assembled.
Remove the previous tonearm base by using the hex wrench (#1.5) to loosen one of the three M3x4
grub screws on the tonearm base (Pic. 5).
When assembling the
base must be able to rotate freely for final fine adjustment. In addition, the side hole with threaded
pin (M6x8) in the tonearm base must remain accessible (Pic. 5).
Make sure the fit is precise and the mounting surfaces are flat.
Pic. 4: Roundbase for Performance DC / Ovation / Reference Jubilee and Master Jubilee turntable (Art. No. AC031-9)
Pic. 5
: Rough alignment of the tonearm base
Page / Seite 8
Unity
tonearm base, please note to not fully tighten the screws yet, as the
Unity
tonearm, it is usually necessary to replace
© clearaudio
electronic GmbH, 2024-10
