The battery for the device is supplied in a partially charged state.
The battery should be charged in conditions where the ambient
0
0
temperature is 4
C - 45
C. A new battery or one that has not been
used for a long period of time will reach full power capability after
approximately 3 - 5 charge and discharge cycles.
• Remove the battery (9) from the unit (Fig. A).
• Plug the charger (10) into a mains socket (230 V AC).
• Slide the battery pack (9) into the charger (10) (Fig. B). Check
that the battery pack is properly seated (inserted all the way in).
When the charger is plugged into a mains socket (230 V AC),
the green LED (11) on the charger will light up to indicate that
the voltage is connected.
When the battery pack (9) is placed in the charger (10), the red
LED (11) on the charger will illuminate to indicate that the battery
is in the process of being charged.
At the same time, the green LEDs (13) of the battery's state of
charge light up pulsatingly in different patterns (see description
below).
• Pulse lighting of all LEDs - indicates battery depletion and the
need to recharge.
• Pulsating illumination of 2 LEDs - indicates partial discharge.
• Pulsating 1 LED - indicates high battery charge.
When the battery is charged, the LED (11) on the charger lights up
green and all the battery charge status LEDs (13) light up
continuously. After a certain time (approx. 15s), the battery charge
status LEDs (13) go out.
The battery should not be charged for more than 8 hours.
Exceeding this time may damage the battery cells. The charger will
not switch off automatically when the battery is fully charged. The
green LED on the charger will remain lit. The battery charge status
LED will turn off after a period of time. Disconnect the power supply
before removing the battery from the charger socket. Avoid
consecutive short charges. Do not recharge the battery after using
it for a short time. A significant drop in the time between necessary
recharges indicates that the battery is worn out and should be
replaced.
Batteries become warm during the charging process. Do not
undertake work immediately after charging - wait until the battery
has reached room temperature. This will prevent damage to the
battery.
BATTERY CHARGING STATE SIGNAL The battery is equipped with
a battery charge status indication (3 LEDs) (13). To check the charge
status of the battery, press the battery charge status indication button
(12) (Fig. C). Lighting of all LEDs indicates a high level of battery
charge. The lighting of 2 diodes indicates partial discharge. The
lighting of only 1 diode indicates that the battery is exhausted and
needs to be recharged.
ADJUSTABLE MAIN HANDLE
Before starting work, the position of the main handle can be
adjusted to be most convenient for the work to be carried out. The
handle can be set in 3 positions by turning it 90
in relation to the basic position. When changing the position of the
main handle, care must be taken not to press the switch button as
this will prevent the handle from rotating.
• Press the main handle lock button (5) (fig. D).
• Rotate the main handle to the desired position.
• Handle
main handle automatically locks into the selected
position.
OPERATION / SETTINGS
ON/OFF
Before starting up, the knife bar cover must be removed and the
battery installed.
The hedge trimmer has a safety switch, requiring the use of both
hands to activate.
Switching on - press the switch lock button (4) and while holding
it down press the switch button (6) (Fig. E).
Switching off - release pressure on the switch button (6) or the
switch lock button (4)
The shears do not operate until the switch lock button (4) is pressed
simultaneously with one hand and the switch (6) is pressed with the
other hand. Releasing the pressure on one of the switches stops
the shears from operating. The safety brake on the movement of
the shears immobilises them in less than 1 s after the switch is
released.
INSTRUCTIONS FOR SAFE USE
Carefully inspect the hedge for invisible objects such as fences,
netting, etc. before starting work.
• When pruning long branches, work should be done gradually, in
• The shears must only be used when the hedge is dry.
• When work is complete, replace the knife bar cover (Fig. F).
HEDGE TRIMMING
• In addition to trimming hedges, shears can also be used to trim
• The best cutting result is obtained by guiding the blade bar so
• The double-sided knife bar and counter-rotating knives allow
• To achieve a uniform hedge height, it is advisable to stretch a
• To guide the branches under the knives, move the knife bar
• The sides of the hedge should be cut using a curved movement,
OPERATION AND MAINTENANCE
• Remove the battery from the unit before carrying out any
• Take care due to the sharp edges of the cutting blades. When
MAINTENANCE AND STORAGE
• It is recommended to clean the device after each use.
• The motor housing should, as far as possible, always be free of
• Wipe the unit with a clean cloth or blow it with low-pressure
• Do not use any cleaning agents or solvents, as these may
• Care must be taken to ensure that no water enters the unit.
• Inspect the shears for obvious defects such as a loose or
• Check that covers and safety devices are undamaged and
• Clean the knife bar after each use and spray it with a
• Check the condition of the knife blades.
• Use only original accessories and original spare parts.
• Store scissors in a safe, dry place that is inaccessible to children.
• Do not place other objects on the shear housing.
O
• Store the device with the battery removed.
to the left or right
Any defects should be rectified by the manufacturer's authorised
service department.
TECHNICAL SPECIFICATIONS
RATING DATA
NOISE AND VIBRATION DATA
10
layers.
shrubs and bushes.
that it is pointed at an angle of approximately 15
cutting in both directions or in a swinging motion (Fig. G).
string or rope along the cut edge of the hedge. Branches that
overhang the marked line should be cut off (Fig. H).
evenly forward or backward along the cutting line.
from bottom to top (Fig. I).
installation, adjustment, repair or operation.
the shears are not in use the knife bar should always be
protected by a guard.
dust and dirt.
compressed air.
damage the plastic parts.
damaged blade, loose screw connections and worn or damaged
components.
properly fitted. Carry out any necessary maintenance and repair
work before using the shears.
preservative spray. During longer jobs, it is recommended to
lubricate the knives with a thin layer of oil at regular intervals
(Fig. J).
Hedge trimmer 58G032
Parameter
Battery voltage
Blade speed without load
Cutting width
Cutting bar length
Maximum cutting thickness
Protection class
Mass
Year of production
58G032 indicates both the type and the machine designation
Sound pressure level
Sound power level
Acceleration value (front
handle)
Acceleration value (rear
handle)
0
to the hedge.
Value
18 V DC
-1
1300 min
510 mm
570 mm
15 mm
III
2.2 kg
2025
L
= 79.1 dB(A) K=3dB(A)
PA
L
= 90.1 dB(A) K=3dB(A)
WA
2
2
a
= 3.845 m/s
K=1.5 m/s
h
2
2
a
= 2.638 m/s
K=1.5 m/s
h
