12 Annex
12.1 Conformities and certificates
8018110.1P3G/2024-10-14 | SICK
Subject to change without notice
1 Center of optical axis, sender
2 Center of optical axis, receiver
3 Potentiometer / yellow LED: status of the received light beam
4 Potentiometer/green LED: Power on
5 Potentiometer / yellow LED: status of the received light beam
6 Mounting hole D4.2 mm
7 Male connector, M12, 5-pin or cable
8 Potentiometer
9 Single teach-in pushbutton
You can obtain declarations of conformity, certificates, and the current operating
instructions for the product at www.sick.com. To do so, enter the product part number
in the search field (part number: see the entry in the "P/N" or "Ident. no." field on the
type label).
