• Ensure that all nuts, pins and screws are securely
tightened so that the product is in a safe working con-
dition.
• Check the grass collection basket regularly for signs
of wear and loss of functionality.
• For safety reasons, replace worn or damaged parts.
• Check that the front and rear wheels are secured.
• To ensure smooth running of the wheels, we recom-
mend cleaning the wheel axles and wheel hubs at
least once per season.
• Any work not described in this operating manual must
be performed by an authorised specialist workshop
only.
• Place the product on a level, even surface.
Tool required:
• Fuel extraction pump*
• Cloth*
• Open-ended spanner/socket spanner, size 17 mm*
• Open-ended spanner/socket spanner, size 10 mm*
• Oil pump*
• Oil collecting tray, flat (for oil change)*
• Collection bucket*
• Copper wire brush*
• Spark plug wrench*
* = may not be included in the scope of delivery!
14.1
Changing the blade (27) (Fig. 1, 18)
WARNING
There is a risk of injury if you work with a
damaged blade.
–
Wear protective gloves!
–
For safety reasons you should only ever have your
blade sharpened and balanced by an authorised
specialist workshop. For optimum results it is rec-
ommended that the blade should be inspected once
a year.
–
When changing the blade, only use original spare
parts.
1. Empty the fuel tank (11) with a fuel extraction pump
before removing the cutting edge. Never tip the lawn-
mower to the side or forwards with a full fuel or oil
tank!
This will damage the engine and void the warranty.
2. Hold the blade (27) tightly with one hand.
3. Turn the blade screw (28) anticlockwise using a open-
end spanner AF17 from the engine spindle (30). Re-
move the washer (29).
4. Re-install the new blade (27) in reverse order. Fasten
the blade screw (28) properly. Make sure that the
blade (27) is correctly positioned and flush against the
engine spindle (30).
5. The tightening torque of the blade screw (28) is
45Nm. Also replace the blade screw (28) when replac-
ing the blade (27).
34 | GB
14.1.1
Should the blade (27) come into contact with an obstruc-
tion, shut down the engine immediately and remove the
spark plug connector (16).
• Check the blade (27) for damage.
• Damaged or bent blades (27) must be replaced.
• Never attempt to bend a bent blade (27) back to
straight again.
• Never mow the lawn with a bent or heavily worn blade
(27) as this will cause vibrations and can lead to fur-
ther damage to the lawnmower.
14.2
Checking the oil level (Fig. 9)
WARNING
Health hazard!
Inhalation of fuel / lubricating oil vapours and exhaust
gases can cause serious damage to health, uncon-
sciousness and in extreme cases death.
–
Do not breathe fuel / lubricating oil vapours and ex-
haust gases.
–
Operate the product outdoors only.
ATTENTION
Product damage!
Using the product without or with too little engine and
gear oil can result in engine damage.
–
Fill with fuel and oil before commissioning. The
product is supplied without engine and gearbox oil.
–
Only use SAE 10W-30 or SAE 10W-40 engine oil.
ATTENTION
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
–
Fill/empty oil only on level, paved surfaces.
–
Use a filling nozzle or funnel.
–
Collect drained oil in a suitable container.
–
Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
–
Dispose of oil as per local regulations.
1. Turn the oil dipstick (18) anticlockwise to unscrew it
and wipe it with a clean, lint-free cloth.
2. Reinsert the oil dipstick (18) and check the oil level
without screwing the dipstick tight again.
3. Pull the oil dipstick (18) out and read the oil level in
the horizontal position. The oil level must be within the
middle mark on the oil dipstick (18).
4. Then screw the oil dipstick (18) in again.
www.scheppach.com
Damaged blades (27)
