7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Assembly
CAUTION
Danger of injury due to rotating blade. Only work on the
product when the blade is switched off and stationary!
Note:
Place the product on a level, even surface.
Tool required:
• Open-ended spanner, size 13 mm*
* = may not be included in the scope of delivery!
8.1 Installation of the lower push
bar (8) (Fig. 3, 4)
1. Align the lower push bar (8) with the corresponding at-
tachment points on the guide plate (9).
2. Attach one M8x50 mm screw (A) through the lower
fastening holes and one M8x30 mm screw (B) through
the upper fastening holes of the guide plate (9) and
the lower push bar (8).
3. Place a washer (D) on each M8x50 mm bolt (A) and
secure them with a plastic star nut (6).
4. Secure each M8x30 mm bolt (B) with an M8 lock nut
(C).
Use a 13 mm open-ended spanner.
8.2 Installation of the upper push bar
(4) (Fig. 1, 5-7)
1. Align the upper push bar (4) with the corresponding
attachment points of the lower push bar (8).
2. Attach one quick-release lever (5) each through the
fastening holes of the upper and lower push bar (4/8).
3. Place a spacer (E) and a washer (D) on each quick-
release lever (5).
4. Secure the quick-release lever (5) with each one plas-
tic star nut (6).
Ensure that the cable of engine brake lever (3), which
will later be attached with a cable clip (7), is not in the
way.
8.3 Installing the pull starter (25)
(Fig. 8)
1. Hook the handle of the pull starter (25) into the cable
hook (24).
9 Before commissioning
ATTENTION
Always make sure the product is fully assembled
before commissioning!
WARNING
Health hazard!
Inhalation of fuel / lubricating oil vapours and exhaust
gases can cause serious damage to health, uncon-
sciousness and in extreme cases death.
– Do not breathe fuel / lubricating oil vapours and ex-
haust gases.
– Operate the product outdoors only.
ATTENTION
Product damage!
Using the product without or with too little engine and
gear oil can result in engine damage.
– Fill with fuel and oil before commissioning. The
product is supplied without engine and gearbox oil.
ATTENTION
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
– Fill/empty oil only on level, paved surfaces.
– Use a filling nozzle or funnel.
– Collect drained oil in a suitable container.
– Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
– Dispose of oil as per local regulations.
ATTENTION
Risk of damage!
If incorrectly stored or undrained fuel is used, the carbu-
rettor may become clogged or engine operation may be
affected.
– Put unused fuel in an airtight vessel and store it in a
dark, cool room.
Place the product on a level, even surface.
