Dismantle the cover plate.
Mark on the position for the hook for fixing the chain. The
hook must be no more than 90 mm away from the bottom
edge of the upper section.
Hang in the pump chains.
Fit the cover plate.
4.12 Installing the level measurement
Pull the protective cap off the level sensor.
Make sure that the distance (L) between the blind plug (3)
and the sensor tip (4) is 630 mm.
Insert the level sensor (1) into the protective tube (2) as
far as it will go.
4.13 Making the electrical connections
General
CAUTION
Electrical work may only be carried out by a skilled electrical firm.
The connections are installed in the factory and should be checked again before starting up for the first time.
Connecting the control unit
Select a suitable position for attachment of the control unit.
Make the connections (pump, level measurement, SonicControl sensor if applicable) as shown on the connection plan
and separate operating instructions.
Perform a functional test.
Note the connection diagram on the inside of the control unit cover.
