3.4 Connections
Description
Inlet
pressure pipe
Direct disposal pipe
Cable conduit
Ventilation pipe
Cable gland (SonicControl)
Emergency outlet (optional)
016-302E
Dimension
DN100 (NS 4)
DN150 (NS 7/10)
DN 80 (OD90)
DN 65 (Storz B coupling)
DN 100
DN 100
M24
DN100 (NS 4)
DN150 (NS 7/10)
Installation and operating instructions
Possible connections
PVC-U pipe
Electro-welded socket,
Clamp connector, KESSEL accessory
(art. no. 28090)
Woven hose with 2 screw clamps
Electro-welded socket
Clamp connector PN 10
Woven hose with 2 screw clamps
PE-U pipe
PE-U pipe
Cable gland
Sealed in the factory
