Information concerning the operating
instructions
These operating instructions are an important aid for ensuring the safe and
reliable functioning of the device.
Reflex Winkelmann GmbH accepts no liability for any damage resulting from
failure to observe the information in these operating instructions. In addition to
the requirements set out in these operating instructions, national statutory
regulations and provisions in the country of installation must also be complied
with (concerning accident prevention, environment protection, safe and
professional work practices, etc.).
These operating instructions describe the device with basic equipment and
interfaces for optional equipment and accessories with additional functions.
Note!
Every person installing this equipment or performing any other work at
the equipment is required to carefully read this manual prior to
commencing work and to comply with its instructions. The manual is to
be provided to the device operator and must be stored near the device
for access at any time.
2
Liability and guarantee
The device has been built according to the state of the art and recognised safety
rules. Nevertheless, its use can pose a risk to life and limb of personnel or third
persons as well as cause damage to the system or other property.
It is not permitted to make any modifications at the device, such as to the
hydraulics or the circuitry.
The manufacturer shall not be liable nor shall any warranty be honoured if the
cause of any claim results from one or more of the following causes:
•
Improper use of the device.
•
Unprofessional commissioning, operation, service, maintenance, repair or
installation of the device.
•
Failure to observe the safety information in these operating instructions.
•
Operation of the device with defective or improperly installed
safety/protective equipment.
•
Failure to perform maintenance and inspection work according to
schedule.
•
Use of unapproved spare parts or accessories.
Prerequisite for any warranty claims is the professional installation and
commissioning of the device.
Note!
Arrange for specialist personnel to carry out commissioning and annual
maintenance.
3
Safety
3.1
Explanation of symbols
The following symbols and signal words are used in these operating instructions.
DANGER
Danger of death and/or serious damage to health
•
The sign, in combination with the signal word 'Danger', indicates
imminent danger; failure to observe the safety information will result in
death or severe (irreversible) injuries.
WARNING
Serious damage to health
•
The sign, in combination with the signal word 'Warning', indicates
imminent danger; failure to observe the safety information can result in
death or severe (irreversible) injuries.
CAUTION
Damage to health
•
The sign, in combination with the signal word 'Caution', indicates
danger; failure to observe the safety information can result in minor
(reversible) injuries.
ATTENTION
Damage to property
•
The sign, in combination with the signal word 'Attention', indicates a
situation where damage to the product itself or objects within its vicinity
can occur.
Note!
This symbol, in combination with the signal word 'Note', indicates useful
tips and recommendations for efficient handling of the product.
3.2
Personnel requirements
Only specialist personnel or specifically trained personnel may install and
operate the equipment.
The electric connections and the wiring of the device must be executed by a
specialist in accordance with all applicable national and local regulations.
3.3
Personal protective equipment
Use the prescribed personal protective equipment as required (e.g. ear
protection, eye protection, safety shoes, helmet, protective clothing, protective
gloves) when working on the system.
Information on personal protective equipment requirements is set out in the
relevant national regulations of the respective country of operation.
3.4
Intended use
The device is used in facility systems for stationary heating and cooling circuits.
The devices may be used only in systems that are sealed against corrosion and
with the following water types:
•
Non-corrosive.
•
Chemically non-aggressive.
•
Non-toxic.
Minimise the entry of atmospheric oxygen throughout the facility system and into
the make-up water.
Note!
Ensure the quality of the make-up water as specified by national
–
3.5
Impermissible operating conditions
The device is not suitable for the following applications:
•
Outdoor operation.
•
For use with mineral oils.
•
For use with flammable media.
•
For use with distilled water.
•
For use with glycol-containing water.
•
For use with chlorine-containing water.
Note!
It is not permitted to make any modifications to the hydraulics or the
3.6
Residual risks
The device has been manufactured using state-of-the-art technology. Despite
this, residual risks always remain.
WARNING
Risk of fire due to open ignition sources
The device housing is made of combustible material and is heat-sensitive.
•
Avoid heat and ignition sources (flames or sparks).
CAUTION
Risk of burns on hot surfaces
Hot surfaces in heating systems can cause burns to the skin.
•
Wear protective gloves.
•
Please place appropriate warning signs in the vicinity of the device.
CAUTION
Risk of injury due to pressurised liquid
If installation, removal or maintenance work is not carried out correctly, there
is a risk of burns and other injuries at the connection points, if pressurised
hot water or hot steam suddenly escapes.
•
Ensure proper installation, removal or maintenance work.
•
Ensure that the system is de-pressurised before performing installation,
removal or maintenance work at the connection points.
Reflex Greenbox — 02.2025
Information concerning the operating instructions
regulations.
For example, VDI 2035 or SIA 384-1.
circuitry.
English — 13
