Data transfer properties and technical data
Data transfer pro-
Transmission technology
perties
Network topology
Medium
Transmission rate
Bus connection
AB Profinet RT
AB Profinet IRT
AB Profinet IRT FO
Process data width
Process data format
Safety features If there is no data transfer, all inputs and outputs are reset and the power source goes
into "Stop" mode. Once data transfer has been re-established, the following signals
resume the process:
-
-
AB Profinet tech-
Power supply
nical data
Installation position
I/O Input
I/O output
Degree of protection
Configuration interface
Device master A device master file is assigned to every node in a Profinet network.
file The device master file contains all the information about the node. It is required for net-
work configuration and can be downloaded from the following website:
http://www.anybus.de/products/profi net/Techn. Dokumentation/GSDML-V1.0-Hms-
ABSPRT
66
"Robot ready" signal
"Source error reset" signal
Ethernet
Star
Twisted pair cable
100 Mbit/s, full duplex mode
Ethernet RJ 45 Harting
Ethernet RJ 45 VarioSub
SCRJ-MM-C V14
296 bits (standard configuration)
Intel
on the rear of the power sources
max. 512 bytes
max. 512 bytes
via field bus configuration module
internal
IP 23
