Fronius AB Profinet RT Bedienungsanleitung Seite 58

Anybus-S Profinet IRT bus module
(1)
(2)
(3)
(4)
(5)
Anybus-S Profinet IRT FO bus module
(1)
(2)
(3)
(4)
(5)
58
(1)
(2)
Interface to UBST 1 PC board
Profinet connection socket - port 1
Profinet connection socket - port 2
Anybus-S status indicator
LED indicator
(1)
(2)
Interface to UBST 1 PC board
Profinet connection socket - port 1
Profinet connection socket - port 2
Anybus-S status indicator
LED indicator
(3) (4)
(3) (4)
(5)
(5)
