Output signals
Seq. no.
(from power
A01
source to robot)
A02
A03
A04
A05
A06
A07
A08
A09 - A16
A17 - A24
A25
A26
A27
A28
A29
A30
A31
A32
A33 - A40
A41 - A48
A49 - A56
A57 - A64
A65 - A72
A73 - A80
A81 - A88
A89 - A96
Signal designation
Arc stable
Not in use
Process active
Main current signal
Welding torch collision protection
Power source ready
Communication ready
Life Cycle Toggle Bit
Error number
Not in use
Not in use
High frequency active
Not in use
Wire available (cold wire)
Not in use
Not in use
Pulse high
Not in use
Welding voltage actual value
High Byte
Low Byte
Welding current actual value
High Byte
Low Byte
Motor current actual value (cold
wire)
Not in use
Arc length actual value (AVC)
Not in use
Range
-
-
-
-
-
-
-
Every 250 ms
0 - 255
-
-
-
-
-
-
-
-
-
0 - 65535 (0 - 100 V)
-
-
0 - 65535 (0 - 1000 A)
-
-
0 - 255 (0 - 5 A)
-
0 - 255 (0 - 50 V)
-
Activity
High
-
High
High
High
High
High
-
-
-
-
High
-
High
-
-
High
-
-
-
-
-
-
-
-
-
-
-
