Product description
4.6.3 Remote control type plate
There is a sticker with the remote control data on the
inside of the battery cover.
4.7

Air distribution in the interior

Fig. 4
The room air is drawn in via the air distributor. In
cooling mode, the warm room air is cooled by the air
conditioning system and flows directly into the interior
via the air distributor. In heating mode, the cool room
air is heated up. The air distributor is located beneath
the ceiling.
1
2
3
Fig. 5
1 On/Off switch
2 Light switch for ambient lighting
(Premium air distributor only)
3
Pairing button
 30 seconds after switching on, the illumination of
the pressed button is faded out so as not to disturb
in the dark.
The air distributor has four individually adjustable
outlets. This allows the airflow to be metered and
distributed evenly and draught-free throughout the
vehicle. The air distributor is so flat that it takes up
hardly any valuable space.
24 EN
Aventa compact 2.G / Aventa compact plus 2.G
2
2
Fig. 6
1 Slider (air distribution front / rear)
2 Air adjustment (at the back in the direction of
travel)
3 Air adjustment (at the front in the direction of
travel)
4
Air adjustment side panels (mortar grey or grey
beige)
5 Air adjustment panels (winter white or pure white)
The air flow can be metered between the front and rear
areas of the vehicle.
4.7.1 Ceiling / floor
The air flow can be directed from the ceiling to the floor.
Fig. 7
4.7.2 Right / left (Premium air distributor only)
There are two individually adjustable air outlets at the
front and rear.
4 5
3
1
3
4 5
