2 GENERAL DESCRIPTION
The EV-TEST100 model is an adapter designed to interface with the electric car charging
stations' sockets (EVSE - Electrical Vehicle Supply Equipment) and perform electrical
safety tests on these devices. The adapter can simulate the presence of an electric vehicle
in order to measure the output voltage signals from the charging stations as well as fault
conditions.
EV-TEST100 can be used in combination with the following HT safety
Model (*)
MACROEVTEST
COMBIG2
COMBIG3
COMBIG2PLUS
COMBITEST425EV
MT-300
COMBI521
SUPERCOMBIS
(*) The list of available models can be changed without notice. In case of doubt contact the after-sales service
Table 1: models list compliance with EV-TEST100 adapter
The adapter has the following features:
•
Use for EVSE stations with charging modes 2 and 3
•
Test cable with Type 1 (USA/MEX/JAP nations) and Type 2 (EU nations) connectors
•
Vehicle simulation via Control Pilot system (CP state)
•
Cable current capacity simulation via Proximity Pilot system (PP state)
•
Fault PE simulation condition
•
Fault condition simulation on the Control Pilot (Fault E)
•
Efficiency check of internal station energy meter (LOAD section)
•
LED indications for system phase detection
•
Terminals for connection to HT tester
•
Protection fuse on LOAD section
•
Test in compliance with IEC/EN61851-1 and IEC/EN60364-7-722 guidelines
Construction
category
Three phase L1-L2-L3-N-PE
CAT IV 300V
Three phase L1-L2-L3-N-PE
EN - 3
EVSE supply system
Sigle phase L-N-PE
Sigle phase L-N-PE
Split phase L1-L2-PE
EV-TEST100
testers:
FW version
2.08 (or higher)
2.09 (or higher)
