Product description
Control elements
4.2
4.2.1 Control panel
10
5
4 Vacuum pressure gauge
8 Manual slide valve
16 Warning device
4.2.1.1
Manual slide valve
Manual slide valve function:
• Sucking in the load: Press the locking button
slide valve (8) spring-loaded in the direction of .
• Release the load: Press the locking button
slide valve (8) against the spring force in the direction of .
52400043
4 8
5 Operating handle
10 Dust filter
16.3 Battery test button Warning device
8
and push the manual
and push the manual
17 / 47
16 16.3
8
