EN (Translation of the original language)
WARNING
WARNING
WARNING
7 TECHNICAL DATA
7.1 PERFORMANCE SPECIFICATIONS
The performance diagram shows flow rate as a function of back pressure.
Functioning Point Absorption (A)
A
(Maximum Flow Rate)
B
(Base system)
C
(By-Pass)
This manual belongs to PIUSI S.p.A. Whole or partial reproduction of this manual is forbidden.
ENFORCE REGULATIONS FOR ELECTRICAL INSTALLATION
ALL WIRING AND ELECTRICAL CONNECTIONS MUST BE PERFORMED
BY AUTHORIZED AND SUITABLY TRAINED PERSONNEL.
Never touch the electric plug or socket with wet hands.
Do not switch the dispensing system on if the network connection cable or impor-
tant parts of the apparatus are damaged, such as the inlet/outlet pipe, nozzle or
safety devices. Replace the damaged pipe immediately.
The electrical connection between the plug and socket must be kept well
away from water.
THE PUMP IS EQUIPPED WITH CURRENT-SENSING PROTECTION. IF IT ACTIVATES TURN
OFF THE PUMP IMMEDIATELY.
THE PUMP IS EQUIPPED WITH PROTECTION AGAINST OVERHEAT-
ING AND OVERLOAD RISKS. SHOULD SUCH DEVICES ACTIVATE, THE
PUMP SHUTS DOWN AUTOMATICALLY, BUT THE MASTER SWITCH IS
NOT TURNED OFF. IT IS IMPORTANT TO STOP THE PUMP USING ITS
SWITCH. THE PUMP RESTARTS AFTER ITS NORMAL OPERATING CON-
DITIONS HAVE BEEN RESTORED.
FAILURE TO OBSERVE THE ABOVE MENTIONED RULES CAN CAUSE SE-
RIOUS ACCIDENTS
SHOULD THE HEAT SENSOR ACTIVATE UNDER NORMAL USE CONDITIONS, PLEASE
CONTACT THE TECHNICAL SUPPORT.
Flow Rate
(l/min) (gpm)
0,7 57 - 15
0,8 40 - 10,5
1,2 0
EX50 230V 50/60Hz
Back Pressure
(bar) (psi)
0,2 - 3
•
0,5 - 7
1,1
Typical delivery
configuration
•
Delivery Closed
