3 Description of the product
3 Description of the product
3.1 General description
Fig.1 Overview
1
90 80 90
1 Building management system (BMS)
2 Gateway
Fig.2 GTW-08 Modbus
80
50
1 6
4 Installation
4.1 Setting the correct address
Fig.3 Rotary dial for identification number
4
The gateway is designed to operate as a communication interface
between a heating and/or cooling appliance and the building management
system (BMS) based on communication protocol Modbus
2
The gateway has the following features:
Monitor the appliances on the BMS.
Control the settings of the appliances from the BMS.
The main components are:
1 L-Bus connectors
2 Dipswitch
2
3 Modbus connectors
3
4 Communication status LEDs
5 Status LED
4
6 Rotary knob
3
5 3
AD-3002800-01
To make sure you are using the correct address to communicate with the
appliance, set the correct address.
By changing the rotary knob you can set the gateway address for the
connected appliance.
Tab.1
Position
0
1
2
3
4
AD-3001547-01
5
6
7
8
3
3 Heating and/or cooling appliance
Gateway addresses
®
.
Gateway address
100Default value
101
102
103
104
105
106
107
108
7854678 - v.01 - 15092023
