5 Configuration
Modbus Data type Description
register
7200 UINT8 The producer activation order
7201 UINT8 List of identified producers on the
cascade system: Number
7202 ENUM8 List of identified producers on the
cascade system : State
7203 UINT16 The minimum power the produc­
er can supply (low load)
7205 UINT16 The maximum power the produc­
er can supply (full load)
7207 UINT16 List of current active producers in
the cascade system
7208 UINT16 Temporary poducer activation or­
der
7209 ENUM8 Current main status of the pro­
ducer.
7228 UINT32 Serial number
Tab.47 Appliance status 7209
Status Description
0 Standby
1 HeatDemand
2 BurnerStart
3 BurningDhw
4 BurningDhw
5 BurnerStop
6 PumpPostRun
7 CoolingActive
8 ControlledStop
9 BlockingMode
10 LockingMode
11 CsModeLCh
12 CsModeHCh
13 CsModeHDhw
14 CsModeCustom
15 ManualHdChOn
16 BoilerFrostProt
17 DeAir
18 CuCooling
19 ResetInProgress
20 AutoFilling
21 Halted
22 ForcedCalibration
23 FactoryTest
24 HydraulicBalancingMode
200 Device Mode
254 Unkown
24
Resolution / Format
0: Not connected
1: Available
2: Not available
1
Explanation
The appliance is in standby mode.
A heat demand is active.
The appliance starts.
The appliance is active for central heating.
The appliance is active for domestic hot water.
The appliance has stopped.
The pump is active after the appliance stopped.
The appliance is active for cooling.
The appliance does not start because the starting conditions are not met.
A blocking mode is active.
A locking mode is active.
Low load test mode for central heating is active.
Full load test mode for central heating is active.
Full load test mode for domestic hot water is active.
The amount of power to be used during the load test in the custom commisioning
mode.
Manual heat demand for central heating is active.
Frost protection mode is active.
The deaeration program operates.
The fan runs to cool the inside of the appliance.
The appliance resets.
The appliance fills the installation.
The appliance has stopped. It must be reset manually.
The forced calibration function is active.
The factory test mode is active.
The hydronic balancing mode is active.
The service tool interface controls the functions of the appliance.
The actual state of the appliance is undefined.
Min - Max Access
0 - 255 R/W
0 - 255 R/W
R/W
R/W
R/W
0 - 255 R
0 - 255 R
See the following ta­ R
ble Tab.47, page 24
0 - 4294967295 R
7854678 - v.01 - 15092023
Display
code
NP231
EP001
EP086
NM113
NM171
EM058
EM228
