5 Configuration
Tab.45 Example for setting zones
Use case
Modbus register
I want to set zone 2 to frost
protection mode (frost protec­
tion mode is the OFF mode)
5.9 Main cascade measures
Tab.46 Main cascade registers
Modbus Data type Description
register
272 UINT8 Current system power received
from consumer manager of the
zone
7000 UINT8 Node number of the device
7001 ENUM8 Cascade Mode
7002 ENUM8 Cascade Type
7009 ENUM8 Type of cascade management
which is requested.
7011 ENUM8 The type of start order permuta­
tion
7012 UINT16 Interval time producer switch
7014 ENUM8 Power control strategy
7015 UINT8 Preferred producer for CH pro­
duction
7016 UINT8 Non preferred producer for CH
production
7017 UINT8 Late on value for next producer
activation
7018 UINT8 Late off value for deactivation of
the producer
7019 UINT8 Early on value for next producer
activation
7020 UINT8 Early off value for deactivation of
the producer
7102 UINT8 Cascade Number of Producer
present recognized in the cas­
cade
7103 UINT8 Number of stage available on the
Cascade
7104 UINT8 Number of stage required on the
Cascade
7105 UINT8 Cascade Power System Re­
quest : Power
7106 INT16 Cascade Power System Re­
quest : Temperature
22
1161
2
1176
x
Values of x are not used.
Resolution / Format Min - Max
0,01 % 0 -100
1 Units 0 - 255
0: Automatic 0 - 2
1: Heating
2: Cooling
0: Traditional 0 - 1
1: parallel
0: Temperature 0 - 1
1: Power
0: Fixed time 0 - 1
1: Operating hours
1 hours 1 - 9999
0: Late on, early off 0 - 2
1: Early on, late off
2: Late on, late off
1 Units 0 - 255
1 Units 0 - 255
% 0 - 100
% 0 - 100
% 0 - 100
% 0 - 100
0 - 255
0 - 255
0 - 255
1% 0 - 100
0,01 °C -20 - 120
Comment
The zone will stay on OFF
mode until you change the
temperature, or you set the
zone back to 0 (Scheduling)
Access Display
code
R
R/W
R/W NP014
R/W NP006
R/W NP011
R/W NP223
R/W NP281
R/W NP225
R/W NP227
R/W NP228
R/W NP282
R/W NP283
R/W NP284
R/W NP285
R NM028
R NM022
R NM023
R
R
