Modbus Data type Description
register
7107 ENUM8 Cascade Power System Re­
quest : Heat demand
7108 UINT8 Cascade System Power Setpoint
calculated : Power
7109 INT16 Cascade System Power Setpoint
calculated : Temperature
7110 ENUM8 Cascade System Power Setpoint
calculated : Heat demand
7151 UINT32 The power (kW) requested from
the cascade system.
7155 INT16 Requested cascade power per­
centage
7157 ENUM8 Status of the cascade primary
pump
7158 ENUM8 Status of the cascade secondary
pump
7159 ENUM8 Cascade state
7160 UINT32 Cascade hours utilized for cen­
tral heating
7162 UINT32 Cascade hours utilized for do­
mestic hot water
7164 INT16 Measured cascade return tem­
perature on secondary side low
loss header (LLH)
7165 UINT8 Cascade, central primary pump
status - producer circuit of low
loss header
7166 UINT8 pwm signal after transfer function
to control pcb-hardware for pump
producer circuit
7167 UINT8 pwm signal after transfer function
to control pcb-hardware for pump
consumer circuit
7168 INT16 Measured cascade flow temper­
ature on secondary side low loss
header (LLH)
7169 INT16 Measured cascade return tem­
perature on secondary side low
loss header (LLH)
7854678 - v.01 - 15092023
Resolution / Format Min - Max
0: Automatic
1: Heating
2: Cooling
3: Process heat
4: Screed drying
5: DHW medium pri­
ority
6: DHW low priority
7: Heating
8: Cooling
9: Electrical active
10: Electrical reactive
1% 0 - 100
0,01 °C -20 - 120
0: Automatic
1: Heating
2: Cooling
3: Process heat
4: Screed drying
5: DHW medium pri­
ority
6: DHW low priority
7: Heating
8: Cooling
9: Electrical active
10: Electrical reactive
0,1 kW
0,1%
0: Inactive
1: Active
0: Inactive
1: Active
See the following ta­
ble Tab.47, page 24
1 hours
1hours
0,01 °C -327,68 - 327,68
1 0 - 14
0,1% 0 - 100
0,1% 0 - 100
0,01 °C -327,68 - 327,68
0,01 °C -327,68 - 327,68
en
5 Configuration
Access Display
code
R
R
R
R
R NM112
R NM170
R NM166
R NM167
R NM163
R NC000
R NC001
R NM165
R
R
R
R EM012
R EM013
