REMEHA GTW-08 Modbus Konfigurationsanleitung Seite 17

5.8.2 Examples of zoning addresses
Tab.27 For an appliance equipped with CU-GH06
Zone
Zone 1
Tab.28 For an appliance equipped with CU-GH06 and SCB-02
Zone
Zone 1
Zone 2
Zone 3
Tab.29 For an appliance equipped with CU-GH08 and SCB-10 and the DHW is managed by CU-GH08
Zone
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
7854678 - v.01 - 15092023
Address
641 and 645 = CircuitA0
Address
641 and 645 = CircuitA0
1153 and 1157 = CircuitA1
1665 and 1669 = DHW
Address
641 and 645 = CircuitA0
1153 and 1157 = DHW
1665 and 1669 = CircuitA1
2177 and 2181 = CircuitB1
2689 and 2693 = DHW1
Tab.26 Zone description
Zone description
Device type
Function type
Important
Check the rotary dial on the board for the correct position for that
zone.
5 Configuration
All available types
ZZ: Device category
YY: number in the category
00: CU-GH
01: CU-OH
02: EHC
14: MK
19: SCB
1B: EEC
1E: Gateway
Disable
Direct
Mixing Circuit
Swimming pool
High Temperature
Fan Convector
DHW tank
Electrical DHW
Time Program
ProcessHeat
DHW Layered
DHW Internal tank
DHW Commercial Tank
Occupied
Board
CU-GH06
Board
CU-GH06
SCB-02
SCB-02
Board
CU-GH08
CU-GH08
SCB-10
SCB-10
SCB-10
en
17
