en
5 Configuration
5.7.2
Reading out the water pressure
Tab.22
Water pressure
Modbus reg
Data type
ister
409
UINT8
5.7.3
Reading out the flow and return temperature
Tab.23
Flow and return temperature for single appliance and cascade
Modbus reg
Data type
ister
400
INT16
401
INT16
7101
INT16
7163
INT16
5.8
Zoning
5.8.1
Zoning addresses
Tab.24
Read number of zones
Modbus reg
Data Type
ister
189
UINT8
Tab.25
Zone function with display code CP02X and device type
Zone
1
2
Func
641
1153
tion
Device
645
1157
16
Description
Water pressure of the primary circuit.
Description
Current system flow temperature from consumer man
ager of the zone
Current system return temperature from consumer
manager of the zone
Cascade flow temperature
Cascade return temperature
In this chapter you will find the number of zones set, the type, and which
control board is related.
Description
Counter of zone detected
3
4
5
1665
2177
2689
1669
2181
2693
Values of x are not used for that particular example.
6
7
8
3201
3713
4225
3205
3717
4229
See
Documentation of the applicable appliance.
Resolution /
Min - Max
Format
0.1 Bar
0.0 – 3.0
Resolution /
Min- Max
Format
0.01 °C
-327.68 -
327.68
0.01 °C
-327.68 -
327.68
0.01 °C
-327.68 –
327.68
0.01 °C
-327.68 –
327.68
Format
0 - 127
9
10
11
4737
5249
5761
4741
5253
5765
7854678 - v.01 - 15092023
Display
code
AM019
Display
code
AM016
AM018
NM001
NM165
Access
R
12
6273
6277
