1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new tool brings you much enjoyment and
success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this device assumes no liability for
damage to the device or caused by the device arising
from:
• Improper handling
• Failure to comply with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists
• Installing and replacing non-original spare parts,
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE 0113 not being observed
Note:
Read the whole text of the operating manual before as-
sembly and commissioning.
This operating manual should help you to familiarise
yourself with your device and to use it for its intended
purpose.
The operating manual includes important instructions
for safe, proper and economic operation of the device,
for avoiding danger, for minimising repair costs and
downtimes, and for increasing the reliability and ex-
tending the service life of the device.
In addition to the safety instructions in this operating
manual, you must also observe the regulations appli-
cable to the operation of the device in your country.
Keep the operating manual at the device, in a plastic
sleeve, protected from dirt and moisture. They must be
read and carefully observed by all operating personnel
before starting the work.
The device may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards.
The required minimum age must be observed.
22 | GB www.scheppach.com
In addition to the safety instructions in this operating
manual and the separate regulations of your country,
the generally recognised technical rules relating to the
operation of such machines must also be observed.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Device description
1. Light switch
2. Speed setting wheel
3. On/off switch
4. Workpiece stop
5. Workpiece stop screw
6. Allen key
7. Saw band
8. Saw band tightening lever
9. Handle
10. Wing screw on the handle
11. Protective covers
12. Locking screws
13. Rubber wheels
14. Guide rollers
15. Handle on the vice
15a. Quick adjustment
16. Vice
17. Cylinder-head screws with hexagon socket
18. Cutting angle adjustment
19. Long wing screw
20. Screw for the cutting angle adjustment
21. Locking pin
21a. Nut
22. Swivel arm
23. Work lamp
24. Saw table
25. Holes
26. Carbon brushes
3. Scope of delivery
• Metal band saw
• Saw table (pre-fitted)
• 4 wing screws, long (pre-fitted)
• Allen key (4 mm)
• Allen key (6 mm)
• Operating manual
4. Proper use
The portable metal band saw with speed setting is ex-
clusively suited for cutting wood, pipes, profiles and
thin non-ferrous metals.
The shape of the workpieces must be such that safe
clamping in the machine vice is possible and such that
the workpiece is prevented from jumping out during
the sawing process.
The machine may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or inju-
ries of any type resulting from this.
Only saw bands that are suitable for the machine may
be used. An element of the intended use is also the
observance of the safety instructions, as well as the
assembly instructions and operating information in the
operating manual.
Persons who operate and maintain the machine must
be familiar with the manual and must be informed
about potential dangers. In addition, the applicable
accident prevention regulations must be strictly ob-
served. Other general occupational health and safe-
ty-related rules and regulations must be observed.
The liability of the manufacturer and resulting dam-
ages are excluded in the event of modifications of the
machine.
The machine may only be operated with original parts
and original accessories from the manufacturer.
The safety, operating and maintenance specifications
of the manufacturer, as well as the dimensions speci-
fied in the technical data, must be observed.
Despite use as intended, specific risk factors cannot
be entirely eliminated. Due to the design and layout of
the machine, the following risks remain:
• Danger of injury to the eyes when the necessary
eye protection is not used.
• Hearing damage when the necessary hearing pro-
tection is not used.
• Harmful emissions of wood dusts during use in en-
closed areas.
• Risk of accident due to contact with the hands in the
uncovered cutting area of the tool.
www.scheppach.com
• Danger of injury during a workpiece change (cut-
ting hazard).
• Danger due to the ejection of workpieces or parts
of the workpiece.
• Crushing of fingers.
• Danger due to kick-back.
• Tilting of the workpiece due to insufficient workpiece
support surface.
• Touching the cutting tool.
• Ejection of branches and workpiece parts.
Please note that our equipment was not designed with
the intention of use for commercial or industrial purpos-
es. We assume no guarantee if the device is used in
commercial or industrial applications, or for equivalent
work.
5. General safety instructions
• WARNING Read all safety information and in-
structions. Failure to observe safety information
and instructions can result in electric shock, fire and/
or serious injuries.
• Save all warnings and instructions for future ref-
erence.
• The term "electrical tool" used in the safety instruc-
tions refers to mains-powered electrical tools (with
a mains cable).
1 Work area safety
• Keep your work area clean and well-lit. Cluttered or
dark areas invite accidents.
• Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite
the dust or fumes.
• Keep children and bystanders away while operating a
power tool. Distractions may cause you to lose con-
trol of the device.
2 Electrical safety
• Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electric shock.
• Avoid body contact with earthed surfaces, such as
pipes, heaters, ovens and refrigerators. There is an
increased risk of electric shock if your body is earthed
or grounded.
