5 Description of Error Codes

No Code/Icon Description
WARNING!
Protection cap is missing
1 21
Rotor is blocked
2 22
Battery is empty
3 23
Rotor calibration is expired
4 32
Memory error:
5 01
• Volume table/Delay Time
Memory error:
6 02
• Calibration Factor (Rotor table)
Memory error:
7 03
• Rotor status (Rotor table)
Memory error:
8 04
• Expiry date (Rotor table)
Memory error:
9 05
• Q A Level (Rotor table)
Possible hardware error:
10 06 • T iming not recognized correctly after
Memory error:
11 07 • T ime conflict Interval Sampling para-
Memory error:
12 08 • C alculation of Interval Sampling
Writing error
13 09
Reading error
14 10
Faulty Bluetooth Communication
16 11
Faulty Bluetooth Communication
17 12
Faulty Bluetooth Data Transfer to PC
18 13
switching the device on
meter (Manual Rotor Calibration only)
para meters
Action
Refer to the user manual!
Mount the protection cap
Verify the correct assembly of the rotor and the protection cap.
Check if the agar strip is inserted correctly
Recharge the battery
Calibration of the rotor is required
Reprogram the individual sample volume/delay time
Calibration of the rotor is required
(Technical Service or CalibSo Software)
Calibration of the rotor is required
(Technical Service or CalibSo Software)
Calibration of the rotor is required
(Technical Service or CalibSo Software)
Reprogram the QA-Level
Adjust the time.
If the error maintains oder continues repair of the instrument
is required. Please contact your Merck Service Provider.
Reprogram the Intervall Sampling parameters
Reprogram the Intervall Sampling parameters
Repair of the instrument is required.
Please contact your Merck Service Provider.
Repair of the instrument is required.
Please contact your Merck Service Provider.
Check the distance of the scanner and repeat the procedure
Check the distance of the scanner and repeat the procedure
Check the PC communication. Eventually, a new installation
of the HYCON-ID Software is required
87
