1 Introduction
1.4 Main Components of the RCS
56
(continued)
® High Flow Touch Microbial Air Sampler
1
1 ON/OFF key
2 High Resolution Color Touchscreen
3 Detachable Air Direction Ring
4 Rotor
5 Guide for positioning the agar strip
6 Opening for air inlet
7 Magnetic coupling flange
8 Protection Cap
9 Bayonet lock for the Protection Cap
2 7
9 3
4 8
5 6
