1 Introduction
60
(continued)
1.7

Ports and Data Transfer

®
The RCS High Flow Touch Microbial Air Sampler is
equipped with a standard RS232 interface for data
transfer between the instrument and a personal
computer (PC). If the PC is not equipped with a serial
interface the use of a suitable USB adapter is
possible. Both the serial RS232 Cable and the USB
adapter are supplied with the instrument.
®
The RCS High Flow Touch Microbial Air Sampler
features a bluetooth option for transfer of air
sampling data to a PC. This requires the optional
HYCON-ID Software.
In combination with the HYCON
optional CalibSo Software allows for the computer
mediated, automated calibration of the instrument
and the management of up to ten rotors.

1.7.1 RS232 Interface

The RS232 interface is located at the bottom of the
device and is secured with a protection cap in order
®
Anemometer the
to prevent fluid entry. Using the serial RS232 cable
the RCS
be connected to a PC. This allows for data transfer
and use of the RCS
1 Install the RCS
2 Remove the protection cap covering the
3 Connect the RCS
4 Start the RCS
NOTE
• The RS232 interface is covered with a protec­
tion cap to prevent exposure to fluids and dust.
It is recommended to remove the RS232 protec­
tion cap only when using the RS232 interface.
®
High Flow Touch Microbial Air Sampler can
®
Management Software:
® Management Software on
the PC
serial interface of the device
®
High Flow Touch Microbial
Air Sampler with the PC by using the serial
RS232 cable
® Management Software after
®
the RCS High Flow Touch is connected with
the PC and is switched on.
