1.7.2 Installation of the USB Adapter

An USB adapter enables a connection between the
®
RCS High Flow Touch instrument and a PC by using
the USB interface of the PC. The USB adapter and
an Installation CD are supplied with the instrument.
The installation of the USB adapter (Windows) is
performed in three steps:
1 Insert the Installation CD into the drive of
the PC and start the program F5U103 In-
staller.exe from the folder F5U103ea driver/
Windows. Quit the installation screens with
< next > and <finish>.
2 Connect the USB adapter cable with the
USB port of the PC. The new hardware is
recognized by the Windows software, the
previously installed drivers are allocated,
and the new hardware is ready for operation.
3 Connect the serial RS232 cable with the
RS232 port of the RCS
Microbial Air Sampler and then with the
USB adapter at the PC.
4 Start the RCS ®
Management Software after
®
the RCS High Flow Touch Microbial Air
Sampler is connected with the PC and
switched on.
NOTE
The use of USB adapters not recommended by
Merck may result in difficulties during installation.
This is a compatibility problem caused by a non­
matching USB driver.
1.7.3 RCS
The RCS
the instrument. It is used to define or change the
user settings by using a PC (see below). The modified
data is then transferred to the RCS
instrument by using the serial RS232 interface
(see chapter 1.7.1 and 1.7.2):
®
High Flow Touch
NOTE
For a detailed description of the RCS
ment Software please refer to the corresponding
User Manual.
® Management Software
®
Management Software is supplied with
1 Interval Sampling: Defines sample collection
cycles consisting of the sampling volume,
the number of cycles, and the total time of
the collection procedure. The RCS
ment Software calculates the parameters
for the interval sampling automatically.
2 Quality Assurance (QA) Level Management:
Allows locking of certain functions for the
operator. Using the functions <manual
change of the calibration factor > (QA Level 2),
the <change of sampling volumes >
(QA Level 3), and the <selection of rotor >
(QA Level 4) by the can prohibited.
3 Time/Date: The date can only be changed
®
by using the RCS Management Software.
This is a security function.
®
High Flow Touch
®
Manage-
®
Manage­
