Replacing com-
ponents Robacta
Twin Compact
Danger due to strongly heated welding torch or hot coolant.
Pro
This can result in burns.
▶
NOTE!
Risk of serious physical damage.
▶
1
3
* A torque wrench and the matching socket wrench are available instead of the
tool supplied as standard. This ensures that it is possible to tighten the compon-
ents with the torque specified. See spare parts list for item number.
Replacing wel- IMPORTANT! Always use two identical contact tubes.
ding torch wea-
ring parts Ro-
bacta Twin
CAUTION!
The exchange of the components as well as the cleaning and check of the
components may only occur in the cooled-down state of the welding torch.
It is imperative that the sequence of work steps is complied with and the tor-
ques specified adhered to.
1
2
1
2
*
3
4
2
1
4
English
4
3
2
1
2
