Dismantling and
assembling Ro-
bacta Twin Com-
pact Pro torch
necks
Connecting the
NOTE!
robot hose pack
Shielding gas mixed with extraneous air has an adverse effect on welding re-
sults.
▶
▶
1
* Connection for torch blow-off option
Correct laying of To attain optimum wirefeed, observe the following when laying the hose pack:
the robot hose -
pack -
-
-
-
The end of the hose must be sealed off with the stopper supplied if the torch
blow-off connection is not in use
Do not connect the hose if no compressed air is connected to the solenoid
valve for the blow-off function. Seal hose with stopper.
1
3
2
4
4
*
Do not kink the hose pack
Arrange the hose pack in as straight a line as possible
Do not overstretch the hose pack, especially in robot mode
Keep bends in the hose pack as wide as possible
Use balancers and hose pack holders (e.g.: Universal hose pack holder)
5
