Comfee Smart Cool 7000 Plus Benutzerhandbuch Seite 25

4
Hung Window Installation
Step 1:
Insert the window slider
assembly into the window
opening.
NOTE:
Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one
of the following two installation methods.
Step 2:
Cut the non-adhesive foam seal C strip to match the width of
the window. Insert the seal between the glass and the window
frame to prevent air and insects from getting into the room.
23
Step 3:
If desired, install the security bracket
with 2 screws as shown.
EN
