Connect the adaptor to the unit and the window
MODEL A
Bolt
Window slider A Window slider B
or
Bolt
Window slider A Window slider C
Window slider B
2
Preparing the Adjustable Window Slider
Choose the window sliders according the size of your window. Sometimes, it needs
to be cut short to meet the window size, please take extra care to cut it properly.
NOTE:
Please base your window slider installation on the accessories in your kit and the width of
your window.
MODEL B
Window
Sliders
1+2：
1+2+3：
Outside
Inside
1+2+3+4：
1+4：
Before assembly
After assembly
Bolt
Bolt Bolt
Bolt Bolt Bolt
Bolt
Use bolts to fasten the window sliders once they
are adjusted to the Proper length.
21
MODEL C
Before assembly
Window
Sliders
After assembly
Bolt
1+2：
Bolt Bolt
1+2+3：
