STULZ GmbH Klimatechnik
Holsteiner Chaussee 283
D 22457 Hamburg
Germany
--------------------------------------------------------------------------------
Auftrags-Nr./
Order No.
:
M e c h a n i s c h e
I
I
Anz.I
ME I Bauteil
Qty I UnitI Component
----I-----I----------------------------------------------------I----------------
2 I M
I Rohr DIN 8905-SF-Cu F22-R-12x1,0
I
I pipe DIN 8905-SF-Cu F22 -R- 12 x 1,0
4 I STK I Kappe f.Schraderventil
I
I flap for schrader valve
4 I STK I Ventileinsatz für Füllventil
I
I valve inlet for charging
1 I STK I Stulz Ablassanschluss 90Grad d=21mm
I
I Stulz Discharging connection 90Degree D=21 mm
1 I STK I Befeuchter-Kit 10-15kg/h
I
I Humidifier-Kit 10-15kg/ h
1 I STK I Front Display Advanced
I
I Front Display Advanced
1 I STK I Front dicht
I
I front closed
1 I STK I Front unten
I
I Front bottom
1 I STK I Front Top
I
I Front Top
1 I STK I Stromwandler TAM weiß
I
I Current transformer TAM white
2 I STK I Kugelabsperrventil Danfoss GBC 12s
I
I ball stop valve
2 I STK I Kugelabsperrventil Danfoss GBC 28s
I
I ball stop valve
1 I STK I Dampfzylinder BLOT3C00H0 380V 10-15kg
I
I steam cylinder BLOT3C00H0 380V 10-15kg
1 I STK I Ablaufventil-Kit
I
I Drain valve - kit
4 I STK I Vorreiber, PA schwarz Dreikant 7mm kpl.
I
I fastener ,PA
1 I STK I Rohr-Kit intern Füll/Ablauf
I
I Hoses internal
1 I M
I Dampfschlauch 22mm blau
I
I Steam hose 22mm
2 I STK I Litze 2 polig mit Steckkontakt
I
I 030105-01
4 I STK I Scharnier Scheibe Kunststoff CyberAir
I
I Hinge disk plastic CyberAir
5 I STK I Schraube/Zyl. DIN
I
I screw/cyl. DIN
78
Ersatzteilliste / Spare Part List
0591161005.02 *
T e i l e
/
ohne Stulz Aufdruck
without Stulz print
Danfoss GBC 12s
Danfoss GBC 28s
black three-edge
84- M 4 x 10 - A2
84- M 4 x
Technisches Handbuch - Planung EC Tower 502 | Version 07-2017 | 1000760
M e c h a n i c a l
7mm cpl
10 - A2
Seite /
Page :
3 /
5
Druckdatum /
Date of print: 27.02.17
C o m p o n e n t s
I STULZ
I Lag.Nr.
I PartNo.
I L10001
I
I L10924
I
I L10927
I
I M24194
I
I M24378
I
I M24462
I
I M24463
I
I M24465
I
I M24674
I
I M26701
I
I M39034
I
I M39039
I
I M46679
I
I M54129
I
I M55764
I
I M57058
I
I M57424
I
I M57996
I
I M58649
I
I M61027
I
