STULZ GmbH Klimatechnik
Holsteiner Chaussee 283
D 22457 Hamburg
Germany
--------------------------------------------------------------------------------
Auftrags-Nr./
Order No.
:
0591161005.02 *
E l e k t r i s c h e
I
I
Anz.I
ME I Bauteil
Qty I UnitI Component
----I-----I----------------------------------------------------I----------------
1 I STK I Schiebeschalter 7A11-A1PCSE2; 1 Wechsler
I
I Slide switch 7A11-A1PCSE2
1 I STK I Klemm-und Steckverbinder
I
I connector for binding and plug in
1 I STK I Buchse mit Zugentlastungsgehäuse 5 polig schwarz
I
I female connector with cord grip box 5 pole black
2 I STK I Buchse mit Zugentlastungsgehäuse 4 polig schwarz
I
I female connector with cord grip box 4 pole black
1 I STK I CompTrol T/F-Fühler S+S 4-20mA digital
I
I CompTrol T/H-sensor S+S 4-20mA digital
11 I STK I 2-Leiter-Durchgangsklemme 1,5/TOPJOB S grau
I
I 2-conductor through clamp 1,5/TOPJOB S grey
2 I STK I Abschlussplatte 2-Leiter-Klemme TOPJOB S orange
I
I end plate 2-conductor clamp TOPJOB S orange
31 I STK I 4-Leiter-Durchgangsklemme 1,5/TOPJOB S grau
I
I 4-conductor through clamp 1,5/TOPJOB S grey
11 I STK I Abschlussplatte 4-Leiter-Klemme TOPJOB S orange
I
I end plate 4-conductor clamp TOPJOB S orange
3 I STK I 4-Schutzleiterklemme 1,5/TOPJOB S grün/gelb
I
I 4-conductor earth clamp 1,5/TOPJOB S green/yellow
24 I STK I 2-Leiter-Trenn- und Messklemme TOPJOB S grau
I
I 2-cable separating measuring clamp TOPJOB S grey
1 I STK I CompTrol 7000 I/O-Controller
I
I CompTrol 7000 I/O-Controller
2 I STK I E-Heizung 1x 9 kW 400/230 V CA3
I
I E-heating 1x 9 kW 400/230 V CA3
1 I STK I G-Sicherungseinsatz T
I
I G-fuse plug T 2,0 A D5,0 x20mm
10 I STK I Koppelrelais kpl. 24VAC
I
I Coupling relay complete 24VAC
4 I STK I Printrelais 24VAC (2 Wechsler)
I
I Printrelay 24VAC
1 I STK I CompTrol 7000 Advanced-Terminal
I
I CompTrol 7000 Advanced-Terminal
1 I STK I Not-Aus-Schalter KG80 4p o. Verriegelung d. Tür
I
I emergency shut-off KG80 4p without lock door
2 I STK I EMV-Filter FN3256H-16-29 3x520V+N/16A
I
I EMC-Filter FN3256H-16-29 3x520V+N/16A
M e c h a n i s c h e
I
I
Anz.I
ME I Bauteil
Qty I UnitI Component
----I-----I----------------------------------------------------I----------------
2 I STK I Vorreiber-Schlüssel Dreikant 7mm
I
I key triangular 7mm
Technisches Handbuch - Planung EC Tower 502 | Version 07-2017 | 1000760
Ersatzteilliste / Spare Part List
T e i l e
/
E l e c t r i c a l
HW7
HW7
2,0 A D5,0 x20mm
2 Wechsler
T e i l e
/
M e c h a n i c a l
Seite /
Page :
Druckdatum /
Date of print: 27.02.17
C o m p o n e n t s
I STULZ
I Lag.Nr.
I PartNo.
I M24751
I
I M24946
I
I M26038
I
I M26042
I
I M26178
I
I M26312
I
I M26315
I
I M26317
I
I M26319
I
I M26320
I
I M26339
I
I M26499
I
I M26768
I
I M37347
I
I M40902
I
I M40903
I
HW3
I 1102189
HW3
I
I 1102474
I
I 1102837
I
C o m p o n e n t s
I STULZ
I Lag.Nr.
I PartNo.
I F09060
I
Stücklisten
2 /
5
77
