iX Series Transmitter Setup
1. Power ON your transmitter and begin once the Spektrtum Airware app is open.
Select the orange pen icon in the upper left corner of the screen, the system
asks for permission to Turn Off RF, select PROCEED
2. Select the three dots in the upper right corner of the screen,
select Add a New Model
3. Select Model Option, choose DEFAULT, select Helicopter.
The system asks if you want to create a new heli model, select Create
4. Select the last model on the list, named Heli.
Tap on the word Acro and rename the file to a name of your choice
5. Tap and hold the back arrow icon in the upper left corner of the screen to
return to the main screen
6. Tap on the Model Setup button
7. Set Flight Mode Setup
Switch 1: Switch B
Hold Switch: Switch H
Tap on the arrow in the upper left corner to return to the Model Setup menu
8. Set Channel Assign
Set Channel input config: set Ch 5 Gear to Flight Mode
Tap on the arrow in the upper left corner to return to the Model Setup menu
Tap on the arrow in the upper left corner to return to the main screen
9. Tap on the Model Adjust button
10. Tap on Dual Rates and Exponential;
Tap on the pull down tab at Channel and select Aileron
Set Switch: Switch F
Move Switch F to the O position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch F to the 1 position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch F to the 2 position
Set Low Rates: 75%/75%, Expo 25%/25%
11. Tap on the pull down tab at Channel and select Elevator
Set Switch: Switch F
Move Switch C to the O position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch C to the 1 position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch C to the 2 position
Set Low Rates: 75%/75%, Expo 25%/25%
12. Tap on the pull down tab at Channel and select Rudder
Set Switch: Switch F
Move Switch C to the O position
Set High Rates: 100%/100%, Expo 45%/45%
Move Switch C to the 1 position
Set High Rates: 100%/100%, Expo 45%/45%
Move Switch C to the 2 position
Set Low Rates: 75%/75%, Expo 45%/45%
13. Tap on the arrow in the upper left corner to return to the Model Adjust menu
14. Tap on Throttle curve
Ensure Switch H is set to the O position
Set the B switch to the 0 position to select the Normal curve
Set the Curve values to
1 2 3
0 50 63 75
15. Set the B switch to the 1 position to select the Stunt #1 curve
Set the Curve values to
1 2 3
90 90 90 90
16. Set the B switch to the 2 position to select the Stunt #2 curve
Set the Curve values to
1 2 3
100 100 100
17. Set the H switch to the 1 position to select the Hold curve
Set the Curve values to
1 2 3
0 0 0
18. Tap on the arrow in the upper left corner to return to the Model Adjust menu
4 5
90
4 5
90
4 5
100 100
4 5
0 0
19. Tap on Pitch curve
Ensure Switch H is set to the O position
Set the B switch to the 0 position to select the Normal curve
Set the Curve values to
1 2 3
30 40 50
20. Set the B switch to the 1 position to select the Stunt #1 curve
Set the Curve values to
1 2 3
0 25 50
21. Set the B switch to the 2 position to select the Stunt #2 curve
Set the Curve values to
1 2 3
0 25 50
22. Set the H switch to the 1 position to select the Hold curve
Set the Curve values to
1 2 3
30 40 50
23. Tap on the arrow in the upper left corner to return to the Model Adjust menu
24. Tap on Mixing
Select P-Mix 1, Select Normal
Select the first INH (for master) and select the I switch
Select the second INH (for slave) and select the Gear Channel
Set the first Rate value to 0% the second to -125%
Set the Offset to 100
Set the Switch to the I button
25. Tap on <Back> in the upper right corner to return to the Mixing menu
26. Tap on the arrow in the upper left corner to return to the Model Adjust menu
27. Tap on the arrow in the upper left corner to return to the main screen
28. Tap on the clock icon in the Timer 1 box
Set to;
Mode: Count Down
Time: 5:00
Switch: Throttle Out
Over Under Trigger: 25%
One Time: Inhibit
29. Tap on the arrow in the upper left corner to return to the main screen
See the Smart Throttle section for
information on telemetry setup
5
4 5
75 100
4 5
75 100
4 5
75 100
4 5
75 100
