Table of Contents
NX and DX Series Transmitter Setup ..................................................................4
iX Series Transmitter Setup ...............................................................................5
Installing the Flight Battery ................................................................................6
Smart Throttle ...................................................................................................7
Throttle Hold .....................................................................................................7
Control Tests .....................................................................................................8
Low Voltage Cutoff (LVC) ...................................................................................9
Understanding the Primary Flight Controls.........................................................9
Pre-Flight Checklist ........................................................................................10
Flying the Blade Eclipse 360 Helicopter ...........................................................10
Removing the Mechanics From the Fuselage .................................................10
Post-Flight Inspections and Maintenance ........................................................11
Length
Height
Main Rotor Diameter
Airframe
Main Motor
Tail Motor
Receiver
Flight Controller
ESC
Swash Servos
Transmitter
Flight Battery
Battery Charger
RFL1205
SPMWS2000
SPMXPSA200
Completion Guide
Scan the QR code to go to the product completion guide for
information on the recommended Powerstage bundle as well as
other compatible batteries and chargers.

First Flight Preparation

• Remove and inspect contents
• Begin charging the flight battery
• Install the flight battery in the helicopter (once it has been fully charged)
• Program your computer transmitter
• Bind your transmitter
• Program Smart telemetry options in your transmitter
• Familiarize yourself with the controls
• Find a suitable area for flying
30.6 in (767mm)
7.6 in (193mm)
30.6 in (767mm)
Blade Eclipse 360
Main Motor: Eclipse 360, (BLH01247)
Tailmotor: Eclipse 360 (BLH01248)
SRXL2 DSMX Remote Serial Telemetry Receiver
FC6250HX Helicopter Flybarless Flight Control (SPMFC6250HX)
Dual ESC 30A 15A: Eclipse 360 (SPMXAHE3015)
Spektrum H3050 Mid-Torq Ultra-Speed Micro Heli Cyclic Servo
DSM2®/DSMX® Compatible Transmitter
3S 11.1V 2200mAh - 3200mAh Smart 30C (or higher) Li-Po with IC3
3S LiPo Battery Compatible (we recomend SPMXC2050)
RealFlight Trainer Edition RC Flight Simulator
WS2000 Wireless Simulator USB Dongle
Smart G2 Powerstage: 3S 2200mAh
Advanced Tuning (Forward Programming) .......................................................11
Troubleshooting Guide .....................................................................................13
Limited Warranty .............................................................................................14
Warranty and Service Contact Information .......................................................14
FCC and Canada Compliance Information ........................................................15
IC Information .................................................................................................15
Compliance Information for the European Union ..............................................15
Exploded View ................................................................................................56
Parts List ........................................................................................................58
Optional Parts ................................................................................................59
Recommended Components ..........................................................................59
Specifications
Tail Rotor Diameter
Flying Weight
Components
Required Equipment
(we recommend SPMX22003S30)
®
Optional Accessories

Flying Checklist

❏ Always turn the transmitter on first
❏ Plug the flight battery into the lead from the ESC
❏ Allow the ESC to initialize and arm properly
❏ Fly the model
❏ Land the model
❏ Unplug the flight battery from the ESC
❏ Always turn the transmitter off last
3
4.7 in (120 mm)
33 oz (935 g)
BNF- Basic (BLH01250)
Included
Installed
Installed
Installed
Installed
Installed
Installed
