NX and DX Series Transmitter Setup
1. Power ON your transmitter, click on scroll wheel, roll to System Setup and click
the scroll wheel. Choose yes.
2. Go to Model Select and choose <Add New Model> at the bottom of the list.
The system asks if you want to create a new model, select Create
3. Set Model Type: Select Helicopter Model Type by choosing the Helicopter.
The system asks you to confirm model type, data will be reset. Select YES
4. Scroll down and select Model Name: Input a name for your model file
5. Scroll up to BACK and press the scroll wheel to return to System Setup
6. Scroll down and select F-Mode Setup
Set to:
Switch 1: Switch B
Hold Switch: Switch H
7. Scroll up to LIST and press the scroll wheel to return to System Setup
8. Scroll down and select Channel Assign
Scroll down on the Channel input config screen and set Ch 5 Gear to F-Mode
9. Scroll up to LIST and press the scroll wheel to return to System Setup
10. Select <Main Screen>, Click the scroll wheel to enter the Function List
11. Scroll down to Rates and Expo and press the scroll wheel
Scroll down to Channel and select Aileron
Set Switch: Switch F
Move Switch F to the O position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch F to the 1 position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch F to the 2 position
Set Low Rates: 75%/75%, Expo 25%/25%
12. Scroll up to Channel and select Elevator
Set Switch: Switch F
Move Switch C to the O position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch C to the 1 position
Set High Rates: 100%/100%, Expo 25%/25%
Move Switch C to the 2 position
Set Low Rates: 75%/75%, Expo 25%/25%
13. Scroll up to Channel and select Rudder
Set Switch: Switch F
Move Switch C to the O position
Set High Rates: 100%/100%, Expo 45%/45%
Move Switch C to the 1 position
Set High Rates: 100%/100%, Expo 45%/45%
Move Switch C to the 2 position
Set Low Rates: 75%/75%, Expo 45%/45%
14. Scroll up to LIST and press the scroll wheel to return to the Function List
15. Scroll down to Throttle Curve and press the scroll wheel
Scroll to the N box for curve selection and press the scroll wheel to select the
Normal curve
Set the Curve values to
1 2 3
0 50 63
16. Scroll to the #1 box for curve selection and press the scroll wheel to select
the Stunt #1 curve
Set the Curve values to
1 2 3
90 90 90
17. Scroll to the #2 box for curve selection and press the scroll wheel to select
the Stunt #2 curve
Set the Curve values to
1 2 3
100 100 100
18. Scroll to the H box for curve selection and press the scroll wheel to select the
Hold curve
Set the Curve values to
1 2 3
0 0 0
19. Scroll up to LIST and press the scroll wheel to return to the Function List
EN
4 5
75 90
4 5
90 90
4 5
100 100
4 5
0 0
20. Scroll down to Pitch curve and press the scroll wheel
Scroll to the N box for curve selection and press the scroll wheel to select the
Normal curve
Set the Curve values to
1 2 3
30 40 50
21. Scroll to the #1 box for curve selection and press the scroll wheel to select
the Stunt #1 curve
Set the Curve values to
1 2 3
0 25 50
22. Scroll to the #2 box for curve selection and press the scroll wheel to select
the Stunt #2 curve
Set the Curve values to
1 2 3
0 25 50
23. Scroll to the H box for curve selection and press the scroll wheel to select the
Hold curve
Set the Curve values to
1 2 3
30 40 50
24. Scroll up to LIST and press the scroll wheel to return to the Function List
25. Scroll down to Mixing and press the scroll wheel
Select Mix 1, Select Normal
Select the first INH (for master) and select the I switch
Select the second INH (for slave) and select the Gear Channel
Set the first Rate value to 0% the second to -125%
Set the Offset to 100
Set the Switch to the I button
26. Scroll up to LIST and press the scroll wheel to return to the Function List
27. Scroll down to Timer and press the scroll wheel
Set to;
Mode: Count Down
Time: 5:00
Start: Throttle Out
Over: 25%
One Time: Inhibit
28. Scroll up to LIST and press the scroll wheel to return to the Function List
29. Scroll up to <Main Screen> and press the scroll wheel
See the Smart Throttle section for
information on telemetry setup
