7.1 Making longitudinal cuts (Fig. 19)
This entails cutting through the workpiece in its
longitudinal direction.
•
As far as possible, place the parallel stop (24)
to the left of the blade (26) for the width requi-
red.
•
Lower the blade guide (11) onto the workpie-
ce. (See 5.5.)
•
Switch on the saw.
•
Use your right hand to press one edge of the
workpiece against the parallel stop (24) while
the flat side rests on the table (15).
•
Guide the workpiece along the parallel stop
(24) and into the blade (26) at a uniform
speed.
•
Important: Long workpieces must be secu-
red against falling off at the end of the cutting
operation. You can use, for example, a roller
stand or similar.
7.2 Making angular cuts (Fig. 20)
•
Set the saw table to the desired angle (see
6.3).
•
Carry out the cut as described in (7.1).
7.3 Free-hand cuts (Fig. 21)
One of the most outstanding features of a band-
saw is the ease with which it allows you to cut
curves and radii.
•
Lower the blade guide (11) onto the workpie-
ce. (See 5.5.)
•
Switch on the saw.
•
Hold the workpiece firmly on the saw table
(15) and guide it slowly into the blade (26).
•
Free-hand cuts should be made at low feed
speed so that you can guide the blade (26)
along the required line.
•
It often pays to first cut off surplus areas
around the curves and corners up to about 6
mm from the line.
•
In the case of curves which are too tight for
the installed blade to cut, you will need to
make a series of close-lying cuts up to the
front of the curved line. The surplus areas will
then drop off when you saw the final radius.
8. Transport
To transport the bandsaw, hold the pedestal (5)
with one hand and the machine frame (25) with
the other hand.
Caution! Never lift or transport the equipment by
its safety partitions.
Anl_TC-SB_200_PLUS_SPK13.indb 29 Anl_TC-SB_200_PLUS_SPK13.indb 29
GB
9. Cleaning, maintenance and
ordering of spare parts
Danger!
Always pull out the mains power plug before star-
ting any cleaning work.
9.1 Cleaning
•
Keep all safety devices, air vents and the mo-
tor housing free of dirt and dust as far as pos-
sible. Wipe the equipment with a clean cloth
or blow it with compressed air at low pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could at-
tack the plastic parts of the equipment. Ensu-
re that no water can seep into the device. The
ingress of water into an electric tool increases
the risk of an electric shock.
9.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
9.3 Ordering spare parts and accessories
Please provide the following information when
ordering spare parts:
•
Type of unit
•
Article number of the unit
•
ID number of the unit
•
Spare part number of the required spare part
For our latest prices and information please go to
www.Einhell-Service.com
Tip! For good results we
recommend high-quality ac-
cessories from
www.kwb.eu
